viii DS7708 2D Vertical Slot Scanner Product Reference Guide
Chapter Descriptions
Following are brief descriptions of each chapter in this guide.
•
Chapter 1, GETTING STARTED provides a product overview and unpacking instructions.
•
Chapter 2, DATA CAPTURE describes parts of the scanner, beeper and LED definitions, and how to use
the scanner.
•
Chapter 3, MAINTENANCE, TECHNICAL SPECIFICATIONS, MOUNTING TEMPLATES provides
information on how to care for the scanner, troubleshooting, technical specifications and mounting
templates to assist in
proper placement of the scanner when attaching it to a surface.
•
Chapter 4, USER PREFERENCES & MISCELLANEOUS OPTIONS provides the programming bar
codes necessary for selecting user preference features and commonly used bar codes to customize how
data is transmitted
to the host device.
•
Chapter 5, IMAGING PREFERENCES provides the programming bar codes necessary for selecting user
preference features for the scanner.
•
Chapter 6, USB INTERFACE provides information for setting up the scanner for USB operation.
•
Chapter 7, RS-232 INTERFACE provides information for setting up the scanner for RS-232 operation.
•
Chapter 8, IBM 468X/469X INTERFACE provides information for setting up the scanner with IBM
468X/469X POS systems.
•
Chapter 9, KEYBOARD WEDGE INTERFACE provides information for setting up the scanner for
Keyboard Wedge operation.
Table e.
Keyboard Wedge Cables
Part Number Description
CBA-K61-S07PAR Keyboard Wedge PS/2 Auto-Detect (7ft. Power Port, Straight), 5V
CBA-K63-S07PAR Keyboard Wedge PS/2 Auto-Detect (7ft. Power Port, Straight), 12V
For the DS7708 with an auxiliary scanner the PWRS-14000-148R
power su
pply is required.
CBA-K65-S15PAR Keyboard Wedge PS/2 Auto-Detect (15ft. Power Port, Straight), 5V
Table f.
IBM Cables
Part Number Description
CBA-M61-S07ZAR IBM 468x/9x (Port 9B) Auto-Detect (7ft. Straight)
CBA-M64-S07ZAR IBM 468x/9x (Port 5) Auto-Detect (7ft. Straight)
CBA-M65-S07ZAR IBM 468x/9x (Port 9B) Auto-Detect (7 ft. Straight), 12V
For the DS7708 with an auxiliary scanner, 12Volt
s from host.
CBA-M66-S15ZAR IBM 468x/9x (Port 9B) Auto-Detect (15ft. Straight), 12V
For the DS7708 with an auxiliary scanner, 12Volt
s from host.
