12 - 2 DS7708 2D Vertical Slot Scanner Product Reference Guide
Symbology Parameter Defaults
Table 12-1 lists the defaults for all symbologies parameters. To change the default values, scan the appropriate
bar codes in this guide. These new values replace the standard defau
lt values in memory. To recall the default
parameter values, scan the Set Default Parameter on page 4-4.
NOTE See Appendix A, STANDARD DEFAULT PARAMETERS for all user preferences, hosts, and
miscellaneous default parameters.
Table 12-1
Parameter Defaults
Parameter
SSI
Number
1
Parameter
Number
2
Default
Page
Number
Enable/Disable All Code Types
12-8
UPC/EAN
UPC-A 01h 1 Enable 12-9
UPC-E 02h 2 Enable 12-10
UPC-E1 0Ch 12 Disable 12-11
EAN-8/JAN 8 04h 4 Enable 12-12
EAN-13/JAN 13 03h 3 Enable 12-13
Bookland EAN 53h 83 Disable 12-14
Bookland ISBN Format F1h 40h 576 ISBN-10 12-15
Decode UPC/EAN/JAN Supplementals
(2 and 5 digits)
10h 16 Ignore 12-17
User-Programmable Supplementals
Supplemental 1:
Supplemental 2:
F1h 43h
F1h 44h
579
580
N/A 12-24
UPC/EAN/JAN Supplemental Redundancy 50h 80 10 12-25
Decode UPC/EAN/JAN Supplemental AIM
ID Format
F1h A0h 672 Combined 12-26
UPC Reduced Quiet Zone F8h 05h 09h 1289 Disable 12-28
Transmit UPC-A Check Digit 28h 40 Enable 12-29
Transmit UPC-E Check Digit 29h 41 Enable 12-30
Transmit UPC-E1 Check Digit 2Ah 42 Enable 12-31
UPC-A Preamble 22h 34 System Character 12-32
UPC-E Preamble 23h 35 System Character 12-34
1
SSI number hex values are used for programming via SSI commands.
2
Parameter number decimal values are used for programming via RSM commands.
