13 - 2 DS7708 2D Vertical Slot Scanner Product Reference Guide
OCR Parameter Defaults
Table 13-1 lists the defaults for OCR parameters. To change any option, scan the appropriate bar code(s)
provided in the Parameter Descriptions section beginning on page 13-3.
NOTE See Appendix A, STANDARD DEFAULT PARAMETERS for all user preferences, hosts, symbologies, and
miscellaneous default parameters.
Table 13-1
OCR Programming Default Table
Parameter SSI Number
1
Parameter
Number
2
Default Page Number
OCR Programming Parameters
OCR-A F1h A8h 680 Disable
13-3
OCR-A Variant F1h ACh 685 Full ASCII
13-4
OCR-B F1h A9h 681 Disable
13-7
OCR-B Variant F1h ADh 685 Full ASCII
13-8
MICR E13B F1h AAh 682 Disable
13-15
US Currency F1h ABh 683 Disable
13-16
OCR Orientation F1h AFh 687
0
o
13-17
OCR Lines F1h B3h 691 1
13-20
OCR Minimum Characters F1h B1h 689 3
13-22
OCR Maximum Characters F1h B2h 690 100
13-22
OCR Subset F1h AEh 686 Selected font
variant
13-23
OCR Reduced Quiet Zone F1h B7h 695 50
13-24
OCR Template F1h 23h 547 54R
13-25
OCR Check Digit Modulus F1h B0h 688 1
13-38
OCR Check Digit Multiplier F1h BCh 700 121212121212
13-39
OCR Check Digit Validation F1h B6h 694 None
13-40
Inverse OCR F2h 58h 856 Regular
13-44
1
SSI number hex values are used for programming via SSI commands.
2
Parameter number decimal values are used for programming via RSM commands.
