Symbol DS7708 - Event Reporting; Decode Event

SSI INTERFACE 10 - 31
Event Reporting
The host can request the decoder to provide certain information (events) relative to the decoder’s behavior.
Enable or disable the events listed in Table 10-3 and on the following pages by scanning the appropriate bar
codes.
Decode Event
SSI # F0h, 00h
Parameter # 256
When enabled, the decoder generates a message to the host upon a successful bar code decode. When
disabled, no notification is sent.
Options:
• Enable Decode Event
• *Disable Decode Event.
Enable Decode Event
(01h)
*Disable Decode Event
(00h)
Table 10-3 Event Codes
Event Class Event Code Reported
Decode Event Non parameter decode 0x01
Boot Up Event System power-up 0x03
Parameter Event Parameter entry error
Parameter stored
Defaults set (and parameter event is
e
nabled by defaul
t)
Number expected
0x07
0x08
0x0A
0x0F
