RS-232 INTERFACE 7 - 5
RS-232 Host Parameters
Various RS-232 hosts are set up with their own parameter default settings. Selecting the ICL, Fujitsu,
Wincor-Nixdorf Mode A, Wincor-Nixdorf Mode B, Olivetti, Omron, or terminal sets the defaults listed in Table
7-2.
Table 7-2
Terminal Specific RS-232
Parameter
Standard
(Default)
ICL Fujitsu
Wincor-Ni
xdorf
Mode A
Wincor-N
ixdorf
Mode
B/OPOS
Olivetti Omron
Transmit Code ID
No Yes Yes Yes Yes Yes Yes
Data
Transmission
Format
Data as is Data/Suffix Data/Suffix Data/Suffix Data/Suffix Prefix/Data/
Suffix
Data/Suffix
Suffix
CR/LF
(7013)
CR (1013) CR (1013) CR (1013) CR (1013) ETX (1002) CR (1013)
Baud Rate
9600 9600 9600 9600 9600 9600 9600
Parity
None Even None Odd Odd Even None
Hardware
Handshaking
None RTS/CTS
Option 3
None RTS/CTS
Option 3
RTS/CTS
Option 3
None None
Software
Handshaking
None None None None None Ack/Nak None
Serial Response
Time-out
2 Sec. 9.9 Sec. 2 Sec. 9.9 Sec. 9.9 Sec. 9.9 Sec. 9.9 Sec.
Stop Bit Select
One One One One One One One
ASCII Format
8-Bit 8-Bit 8-Bit 8-Bit 8-Bit 7-Bit 8-Bit
Beep On <BEL>
Disable Disable Disable Disable Disable Disable Disable
RTS Line State
Low High Low Low Low = No
data to
send
Low High
Prefix
None None None None None STX (1003) None
*In the Nixdorf Mode B, if CTS is Low, scanning is disabled. When CTS is High, the user can scan bar codes.
**If Nixdorf Mode B is scanned without the scanner connected to the proper host, it may appear unable to scan. If this
happens, scan a dif
ferent RS-232 host type within 5 seconds of cycling power to the scanner.
