4 - 2 DS7708 2D Vertical Slot Scanner Product Reference Guide
Scanning Sequence Examples
In most cases, scanning one bar code sets the parameter value. For example, to set the beeper tone to high,
scan the High Tone (beeper tone) bar code in the Beeper Tone section on page 4-8. Other parameters, such
as Serial Response Timeout or Data
Transmission Formats, require scanning several bar codes. See these
parameter descriptions for this procedure.
Errors While Scanning
Unless otherwise specified, to correct an error during a scanning sequence, just re-scan the correct parameter.
User Preferences/Miscellaneous Options Parameter Defaults
Table 4-1 lists defaults for user preferences parameters. To change the default values, scan the appropriate
bar codes in this guide. These new values replace the standard defau
lt values in memory. To recall the default
parameter values, scan the Set Default Parameter on page 4-4.
NOTE See Appendix A, STANDARD DEFAULT PARAMETERS for all user preferences, hosts, symbologies, and
miscellaneous default parameters.
Table 4-1
User Preferences Parameter Defaults
Parameter SSI Number
1
Parameter
Number
2
Default
Page
Number
User Preferences
Set Default Parameter N/A N/A Set Defaults
4-4
Parameter Bar Code Scanning ECh 236 Enable
4-6
Beep After Good Decode 38h 56 Enable
4-7
Beeper Tone 91h 145 High
4-8
Beeper Volume 8Ch 140 High
4-11
Beeper Duration F1h 74h 628 Medium
4-13
Volume/Tone Button Control F8h 05h 07h 1287 Enable (both)
4-15
Suppress Power-up Beeps F1h D1h 721 Do not suppress
4-17
Timeout Between Decodes, Same Symbol 89h 137 0.5 Sec
4-18
Timeout Between Decodes, Different Symbols 90h 144 0 Sec
4-18
Fuzzy 1D Processing F1h 02h 514 Enable
4-19
Decode Mirror Images (Data Matrix Only) F1h 19h 537 Auto
4-20
PDF Prioritization F1h CFh 719 Disable
4-22
1
SSI number hex values are used for programming via SSI commands.
2
Parameter number decimal values are used for programming via RSM commands.
