SYMBOLOGIES 12 - 149

2D Symbologies

Enable/Disable PDF417

SSI # 0Fh

Parameter # 15

Enable or disable PDF417.

Options:

•

*Enable PDF417

•

Disable PDF417.

*Enable PDF417

(01h)

Disable PDF417

(00h)
