DATA CAPTURE 2 - 5
Parameter Programming
Entry Error Low, high beeps Red Input error: incorrect bar code,
programming sequence, or
Cancel
scanned.
Number Expected High, low beeps Green Number expected. Enter value
using numeri
c bar codes.
Parameter Entered High, low, high, low
beeps
Gree
n Successful program exit with
change in parameter setting.
ADF Programming
(Refer to the Advanced Data Formatting Programmer Guide, p/n 72E-69680-xx. for ADF bar codes.)
Number Expected High, low beeps Green Enter another digit. Add leading
zeros to the front i
f necessary.
Alpha Expected Low, low beeps Green Enter another alphabetic
character or scan
the
End of
Message
bar code.
Criteria Action Expected High, high beeps Green blinking ADF criteria or action is
expected. Enter a
nother criterion
or action, or scan the
Save Rule
bar code.
Rule Saved High, low, high, low
beeps
Green (tu
rns off blinking) Rule saved. Rule entry mode
exited.
Criteria Action Cleared High, low, low beeps Green All criteria or actions cleared for
current rule
. Continue entering
rule.
Last Rule Deleted Low beep Green Delete last saved rule. The
current rule is left in ta
ct.
All Rules Deleted Low, high, high beeps Green All rules are deleted.
Out Of Rule Memory Low, high, low, high
beeps
Red Out of ru
le memory. Erase some
existing rules, then try to save
rule again.
Cancel Rule Entry Low, high, low beeps Green (turns off blinking) Cancel rule entry. Rule entry
mode exited beca
use of an error,
or the user asked to exit rule
entry.
Rule Error Low, high beeps Red Entry error, wrong bar code
sc
anned, or criter
ia/action list is
too long for a rule. Re-enter
criterion or action.
Macro PDF
Table 2-2
Beeper and LED Indicators (Continued)
Event Beeper Sequence LED Description
Unless otherwise specified, both red and green LEDs display across all three LED indicators (center and
outer).
