A - 2 DS7708 2D VERTICAL SLOT PRESENTATION SCANDS7708 2D Vertical Slot Scanner Product Reference
Field of View F1h 61h 609 Full Field of View 4-26
Miscellaneous Options
Transmit Code ID Character 2Dh 45 None 4-28
Prefix Value 63h, 69h 99, 105 7013 <CR><LF> 4-29
Suffix 1 Value
Suffix 2 Value
62h, 68h
64h, 6Ah
98, 104
100, 106
7013 <CR><LF> 4-30
Scan Data Transmission Format EBh 235 Data as is 4-32
FN1 Substitution Values 67h, 6Dh 103, 109 7013 <CR> <LF> 4-36
Unsolicited Heartbeat Interval F8h 04h 5Eh 1118 Disable 4-38
Imager Preferences
Operational Modes N/A N/A N/A 5-4
Snapshot Mode Timeout F0h 43h 323 0 (30 seconds) 5-5
Image Size (Number of Pixels) F0h 2Eh 302 Full 5-6
Image Brightness (Target White) F0h 86h 390 180 5-8
JPEG Image Options F0h 2Bh 299 Quality 5-9
JPEG Target File Size F1h 31h 561 160 kB 5-10
JPEG Quality and Size Value F0h 31h 305 65 5-11
Image Enhancement F1h 34h 564 Low (1) 5-12
Image File Format Selection F0h 30h 304 JPEG 5-14
Image Rotation F1h 99h 665 0 5-16
Bits per Pixel (BPP) F0h 2Fh 303 8 BPP 5-24
Signature Capture 5Dh 93 Disable 5-20
Signature Capture Image File Format
Selection
F0h 39h 313 JPEG 5-21
Signature Capture Bits per Pixel (BPP) F0h 3Ah 314 8 BPP 5-24
Signature Capture Width F4h F0h 6Eh 366 400 5-25
Signature Capture Height F4h F0h 6Fh 367 100 5-26
Signature Capture JPEG Quality F0h A5h 421 65 5-27
Video View Finder F0h 44h 324 Disable 5-28
Video View Finder Image Size F0h 49h 329 1700 bytes 5-29
Table A-1 Standard Default Parameters Table (Continued)
Parameter SSI Number
1
Parameter
Number
2
Default
Page
Number
1
SSI number hex values are used for programming via SSI commands.
2
Parameter number decimal values are used for programming via RSM commands.
