TimeHub 5500 TL1 Reference Manual
Performance Monitoring
097-55501-02 Issue 5: June 2003
SSSSSSSSSSS SSSS S SSSSS SSSSSSS S SSS S SSSSS S
4
Maximum Relative Time Interval Error (cont’d)
Response Example:
SYMMBITS 00-06-15 12:07:38
M SC1 COMPLD
"CLK1-4:MRTIE-1S,2.000000,COMPL,,,75-MIN"
"CLK1-4:MRTIE-1M,2.000000,COMPL,,,75-MIN"
"CLK1-4:MRTIE-15M,2.000000,COMPL,,,75-MIN"
"CLK1-4:MRTIE-30M,2.000000,COMPL,,,75-MIN"
"CLK1-4:MRTIE-1H,2.000000,COMPL,,,75-MIN"
"CLK1-4:MRTIE-2H,NA,NA,,,75-MIN"
"CLK1-4:MRTIE-8H,NA,NA,,,75-MIN"
"CLK1-4:MRTIE-24H,NA,NA,,,75-MIN"
;
The response in this example shows MRTIE values calculated over the past
75 minutes for observation time intervals of 1 second, 1 minute, 15 minutes,
30 minutes, and 1 hour for input port 4 of clock card 1. The values for time
intervals of 2 hours, 8 hours, and 24 hours are not yet available, but will become
available as the system collects data.
