TimeHub 5500 TL1 Reference Manual

Commands

097-55501-02 Issue 5: June 2003

SSSSSSSSSSS SSSS S SSSSS SSSSSSS S SSS S SSSSS S

Edit Sync (cont’d)

ED-SYNC[-TSG]:[<tid>]:<aid>:<ctag>:::<measurement>=<value>;

Note:

For detailed descriptions of keywords, see the Keywords chapter.

Command Examples:

ED-SYNC::S1-OUTA-3:SC001:::SQUELCH=Y;

The command in this example turns off output channel 3 of output card A in shelf

ED-SYNC::CLK-5:SC001:::PRIORITY=1,ENABLE=Y;

The command in this example sets the priority of input channel 5 and enables the

input channel.

ED-SYNC::CLK-0&&4:SC001:::ENABLE=Y;

The command in this example enables input channels 0 through 4, inclusive.

Parameter Value Variables Description

<aid> CLK-a a = 0 – 4

(5- and 9-input

clocks)

0 = PRS (5 or 10 MHz)

1 – 4 = DS1 terminated inputs

5 – 8 = DS1 bridged inputs

10 = CC 1 input

11 = CC 2 input

a = 5 – 8

(9-input clocks

only)

a = 10 – 11

(remote shelf)

Sa-OUTb-c

a = 0 – 4 Shelf number (0 is main shelf). This prefix is

optional for main shelf.

<measurement> FFOF — Fractional Frequency Offset

LMRTIE Latest Maximum Relative Time Interval Error

MRTIE Maximum Relative Time Interval Error

SPRD Frequency Spread

TDEV Time Deviation

TIE Time Interval Error

<value> See the Keywords chapter
