Technogym Group Cycle D92 - Page 175

3
Figure 185
2. Remove the screw (3) of the limit rod,
with a 4 mm ratchet wrench.
3. Remove the limit.
4
4
Figure 186
4. Remove the screws (4) with a 4 mm Allen
wrench.
New Group Cycle (D92):
Technical Service Guide - Rev. 5.1
Document uncontrolled when printed
Page 175
