Technogym Group Cycle D92 - Page 176

2
Figure 187
5. Remove the post (2).
7
2
Figure 188
Connect Version.
6. Remove the cable (7) from the post (2).
WARNING: be very careful during this
operation to avoid damaging the cable
(7).
For the Connect Version, before inserting
the post, insert the cable (7).
New Group Cycle (D92):
Technical Service Guide - Rev. 5.1
Document uncontrolled when printed
Page 176
