15
Figure 194
14. Work from both sides to loosen the lever
(15) and remove the lever (15) from the
seat post.
17
16
Figure 195
15. Remove the bush (16) and the pin (17).
18
18
Figure 196
16. Remove the screws (18) with a 3 mm Al-
len wrench.
New Group Cycle (D92):
Technical Service Guide - Rev. 5.1
Document uncontrolled when printed
Page 179
