Technogym Group Cycle D92 - Page 185

6
9
Figure 206
7. Unhook the tooth (9).
8. Tighten the screw (6) with a 3 mm Allen
wrench, to eliminate any play.
Do not overtighten! The handlebar must
slide.
4
4
8
Figure 207
9. Position the cover (8).
10. Tighten the screws (4) with a 4 mm Allen
wrench.
Fit the handlebar back on the bike as indicated
in “11.6.1 Removing the handlebar”.
New Group Cycle (D92):
Technical Service Guide - Rev. 5.1
Document uncontrolled when printed
Page 185
