Technogym Group Cycle D92 - Page 189

7
6
Figure 215
6. Remove the screw (6) with a medium
Phillips screwdriver.
7. Remove the other cover (7).
8
Figure 216
8. Remove the screw (8) with a 2.5 mm Allen
wrench.
9
Figure 217
9. Remove the cover (9).
New Group Cycle (D92):
Technical Service Guide - Rev. 5.1
Document uncontrolled when printed
Page 189
