3
Figure 238
4. Remove la rear platform (3).
5. Rotate the bike back to its original posi-
tion.
4
4
Figure 239
6. Loosen the screws (4) with a 4 mm Allen
wrench.
5
Figure 240
7. Remove the screws (5) with a 3 mm Allen
wrench.
New Group Cycle (D92):
Technical Service Guide - Rev. 5.1
Document uncontrolled when printed
Page 199
