Section 10: Using a Micromanipulator 8860 Prober Model 4200A-SCS Prober and External Instrument Control
10-28 4200A-913-01 Rev. A December 2020
Commands and error symbols
The following list contains error and status symbols listed by command.
Available commands and responses
PrChuck
PrInit
PrMovNxt
PrSSMovNxt
PR_OK
X
X
X
X
BAD_CHUCK
X
X
UNINTEL_RESP
X
X
X
X
UNEXPE_ERROR
X
SET_MODE_FAIL
X
INVAL_PARAM
X
SET_UNITS_FAIL
X
SET_DIE_FAIL
X
BAD_MODE
X
X
PR_WAFERCOMPLETE
X
MOVE_FAIL
X
X
PR_MOVECOMPLETE
X
Information and error code return values and descriptions
Value
Constant
Explanation
1
PR_OK
Success (OK)
2
PR_MOVECOMPLETE
Prober moved to next die (confirmed)
4
PR_WAFERCOMPLETE
Next wafer loaded (confirmed)
-1005
SET_UNITS_FAIL
Failure setting units
-1006
SET_MODE_FAIL
Failure setting mode
-1009
SET_DIE_FAIL
Failure setting die size
-1011
BAD_MODE
Operation invalid in mode
-1013
UNINTEL_RESP
Unintelligible response
-1014
MOVE_FAIL
Movement failure
-1015
UNEXPE_ERROR
Unexpected error
-1017
BAD_CHUCK
Bad chuck position
-1027
INVAL_PARAM
Invalid parameter
