Cascade Summit 12000 prober software
The Summit 12000 prober will have one of the following software products installed. Use either of the
following software products to configure and operate the Summit 12000 prober with the Keithley
Instruments 4200A-SCS:
• Velox prober control software: Provides acces to configuration and help programs
or
• Nucleus UI prober control software: Provides access to configuration and help programs
Software version
The following software versions were used to verify the configuration and remote command set of the
Summit-12000 prober with the 4200A-SCS:
• Velox ver. 2.3
or
• Nucleus UI ver. 2.0
Probe station configuration
Make sure that you are familiar with the Summit-12000 Prober and its supporting
documentation before attempting setup, configuration, or operation.
The general steps required to set up and configure the Summit-120000 prober for use with the
4200A-SCS:
• Set up communications (on page 12-2)
• Set up wafer geometry (on page 12-8)
• Create a site definition and define a probe list (on page 12-12)
• Load, align, and contact the wafer (on page 12-15)
