Tektronix Keithley 4200A-SCS User Manual

Section 2: Using switch matrices Model 4200A-SCS Prober and External Instrument Control
2-20 4200A-913-01 Rev. A December 2020
Figure 18: 4200A-SCS signal paths through a 3-pole matrix card using remote sensing
C-V Analyzer signal paths
The following figures show local sense C-V Analyzer signal paths through rows B and H of a 7072
matrix card. A C-V analyzer can be used with any of the three matrix card types; however, rows G
and H of the 7072 are optimized for C-V measurements.
