Model 4200A-SCS Prober and External Instrument Control Section 4: Using a Model 590 C-V Analyzer
4200A-913-01 Rev. A December 2020 4-31
Reading_rate valid inputs
Range
100 kHz values
1 MHz values
2E-12
2 pF low comp value
2 pF low comp value
2E-12
2 pF high comp value
2 pF high comp value
20E-12
20 pF low comp value
20 pF low comp value
20E-12
20 pF high comp value
20 pF high comp value
200E-12
200 pF low comp value
200 pF low comp value
200E-12
200 pF high comp value
200 pF high comp value
2E-9
2 nF low comp value
2 nF low comp value
2E-9
2 nF high comp value
2 nF high comp value
If the file defined for CabCompFile does not exist, or there is no path specified (null string), the
default compensation parameters are used. When entering the path, use two backslash (\\)
characters to separate each directory. For example, if your cable file is in
C:\calfiles\590cal.dat, you enter the following:
C:\\calfiles\\590cal.dat
If a switch matrix to route signals is being controlled by a connection action (for example, connect),
there is no need to connect InputPin and OutPin. Set these parameters to 0.
The return values from status can be:
• 0: OK.
• -10021 (COMP_FILE_NOT_EXIST): The specified compensation file does not exist.
• -10022 (KI590_NOT_IN_KCON): There is no CMTR defined in your system configuration.
Also see
SaveCableCompCaps590 user module (on page 4-32)
LoadCableCorrectionConstants
LoadCableCorrectionConstants reads the cable compensation parameters for the range and frequency
specified from the cable compensation file and sends these parameters to the 590.
Usage
status = LoadCableCorrectionConstants(char *CabCompFile, char *instr_id, *frequency,
int range);
status
Returned values are placed in the Analyze sheet; see Details
CabCompFile
The complete name and path for the cable compensation file; see Details
instr_id
The CMTR instrument ID; this can be CMTR1 through CMTR4, depending on the
configuration of your system
frequency
The frequency of the correction constant: 0 = 1 MHz; 1 = 100 kHz
range
The range of the correct constant; see Details
