Tektronix Keithley 4200A-SCS User Manual

Section 4: Using a Model 590 C-V Analyzer Model 4200A-SCS Prober and External Instrument Control
4-32 4200A-913-01 Rev. A December 2020
Details
If the file specified by CapCompFile does not exist, it is created. The path that you specify must exist.
When entering the path information, be sure to use two \ characters to separate each directory level.
For example, if your cable compensation file is in file C:\calfiles\590cal.dat, you would enter
C:\\calfiles\\590cal.dat.
range values
Range
100 kHz values
1 MHz values
1
2 pF/2 μs
20 pF/200 μs
2
20 pF/20 μs
20 pF/200 μs
3
200 pF/200 μs
200 pF/2 ms
4
2 nF/2 ms
2 nF/20 ms
The return values from status can be:
• 0: OK.
• -10000 (INVAL_INST_ID): An invalid instrument ID was specified. This generally means that
there is no instrument with the specified ID in your configuration.
• -10020 (COMP_FILE_ACCESS_ERR): There was an error accessing the cable compensation
file.
• -10021 (COMP_FILE_NOT_EXIST): The specified compensation file does not exist.
• -10022 (KI590_NOT_IN_KCON): There is no CMTR defined in your system configuration.
Also see
SaveCableCompCaps590 user module (on page 4-32)
SaveCableCompCaps590 user module
This function saves the nominal values of the capacitors used to do the 590 cable compensation procedure to the
indicated file. If no cable compensation file exists, this module creates one if the user has the proper system
permissions.
Usage
status = SaveCableCompCaps590(char *CabCompFile, double Lo2p100k, double Lo2p1M, double
Hi2p100k, double Hi2p1M, double Lo20p100k, double Lo20p1M, double Hi20p100k, double
Hi20p1M, double Lo200p100k, double Lo200p1M, double Hi200p100k, double 200p1M,
double Lo2n100k, double Lo2n1M, double Hi2n100k, double Hi2n1M);
status
Returned values are placed in the Analyze sheet; see Details
CabCompFile
The complete name and path for the cable compensation file; see Details
Lo2p100k
The nominal value of the low-range capacitor used for cable compensation for the 2
pF range and 100 kHz frequency: 0 F to 0.95E-12 F
Lo2p1M
The nominal value of the low-range capacitor used for cable compensation for the 2
pF range and 1 MHz frequency: 0 F to 0.95E-12 F
Hi2p100k
The nominal value of the high-range capacitor used for cable compensation for the
2 pF range and 100 kHz frequency: 1E-12 F to 2E-12 F
