Section 2: Using switch matrices Model 4200A-SCS Prober and External Instrument Control
2-18 4200A-913-01 Rev. A December 2020
Sense setting
To make the connections shown in 4200A-SCS signal paths (on page 2-17), you must select remote
sensing.
When remote sensing is selected, the rows and columns are paired together as follows:
Row A (force) paired with row B (sense)
Column 1 (force) paired with column 2 (sense)
Row E (force) paired with row F (sense)
Column 3 (force) paired with column 4 (sense)
When the FORCE matrix switches are closed by the ConnectPins user module, the SENSE matrix
switches are also closed.
For local sensing (2-wire), the connections from the SENSE terminals of the 4200A-SCS are
not used.
For more information regarding local and remote sense, refer to “Remote sensing” in the•Model
4200A-SCS Source-Measure Unit (SMU) User's Manual.
Connection setting
The row-column setting must be used when connecting instrumentation to matrix rows, as shown in
4200A-SCS signal paths (on page 2-17).
The maximum number of rows available to the test system is eight. If instrumentation needs more
than eight pathways, they must be connected to matrix columns, and the instrument card setting must
be used.
The figure below shows a test system with both the instruments and the DUT connected to
matrix columns.
See Connection scheme settings (on page 2-13) for details on the row-column and instrument card
settings.
