Model 4200A-SCS Prober and External Instrument Control Section 4: Using a Model 590 C-V Analyzer
4200A-913-01 Rev. A December 2020 4-11
Figure 57: CvSweep590 user module (590-cvsweep UTM)
7. Change the test parameters as needed.
8. Execute the test by clicking Run.
This test uses the CvSweep590 user module. For details on this test description, see CvSweep590
user module (on page 4-26).
If you use the default parameters, this test causes the 590 to do a −4 V to +6 V staircase sweep using
50 mV steps. The figure below shows the default sweep.
