Topcon X35 - Power Extension Harness

X35 console System Components
1.5
1.4.2 Power Extension Harness
Power extension harness connects X35 console to
the power source. There are two power extension
harnesses available:
1. with the auxiliary connector to connect in the
cab (3151-69, refer to
Figure 1.7).
2. with leads to connect to the battery and
switched power source (3151-68, refer to
Figure 1.8).
Figure 1.8 - Power Extension Harness (3151-68)
Figure 1.7 - Power Extension Harness (3151-69)
