X35 Monitor System Settings
4.2
This section explains how to set up system
elements such as GPS, auxiliary connections,
alarms and others.
Note
Only features that are registered for the product
purchased can be enabled. Guidance is always
enabled as it is a standard feature.
Select System icon from the main menu to access
system setup menu (Figure 4.1).
4.1 Features
To access the features setup menu from the Main
Setup menu select System/Features, refer to Figure
4.1.
This option will allow you to setup different
features related to the console, guidance system
and implement.
4.1.1 Licenses
Refer to Figure 4.1.
This page shows the features that are unlocked
on the console. It also allows you to export
the license data file which is used by Topcon to
generate a new license data file for the specific
console to be imported to unlock new features if
desired.
4.1.2 Console
To access the console features settings from the
Main Setup menu, select System/Features/Console,
refer to Figure 4.2.
1. Universal Terminal - enables or disables the
ISOBUS Universal Terminal server that allows
interaction with ISOBUS compliant ECUs.
2. ISOBUS Shortcut Button - enabling this
option adds a button above the master switch
that will turn off functions that were activated
through the ISOBUS control. This is not used
by Bourgault.
Figure 4.1 - System Setup Menu
