Topcon X35 Operator's Manual

X35 Monitor Air Seeder Setup
6.11
6.2.2 Create a Custom Implement
Profile
To create a new custom implement profile, select
the Implement/New/Custom and follow the
instructions below:
1. For Air Seeder type;
a. Refer to Figure 6.10.
b. There are four types available: rigid,
header, pivoted (trailing) and double
pivoted (leading):
i. For a trailing air seeder select the
PIVOT icon;
ii. For a leading air seeder select
DOUBLE PIVOT icon.
c. Use the arrows to choose the type. Press
on the appropriate icon.
Figure 6.10 - Air Seeder Type
Rigid
Header
Double Pivot
Pivot
d. A window will appear informing you that
the system will restart once your air seeder
has been configured, refer to Figure 6.9.
e. Select OK to continue.
Figure 6.9 - Restart Required
