X35 Console General Operations
8.33
8.9.2 6000 Series Air Seeder
With the seeding implement in the field position,
but with the seed boots out of the ground:
1. Ensure that the air seeder fan(s) are running.
2. From the menu in the Seeder Controller select
Configuration.
a. In the Configuration panel select Multi-
Tank Calibration.
i. The Calibration Method window will
appear.
ii. Select Automatic Calibration.
iii. Make sure that the Calibration type
set to Stationary, if it is not, change
it.
iv. Proceed to the next screen - Step
2/4.
v. This will put console into calibration
mode.
3. Go to the air seeder tank. Turn on the
hydraulic calibration ball valve.
4. Using the on-frame switchbox, turn on the tank
switches for those meters that will be applying
product.
5. Turn the Master Switch ON to meter the
desired amount of product, then turn it OFF.
Then shut off the hydraulic calibration ball
valve.
6. Proceed to the seeding implement and check
each of the product runs for material on the
ground.
7. If there is no product at an opener, it may
be possible that the secondary manifold and/
or hose supplying product to that opener is
plugged. Refer to
Troubleshooting section in
the operator's manual for your air seeder.
8. Return to the cab.
9. Cancel out of the calibration mode without
proceeding to the next steps in the calibration
wizard.
Important
Ensure that the hydraulic calibration ball valve is
in the “off” position before continuing with normal
operation.
