X35 Monitor Air Seeder Setup
6.66
6.6.6.6 General Output
This setting allows you to assign a relay output
from one of the ECU drives. It is not supported
through Bourgault harnessing.
6.6.6.7 Drill Fold Setup
This allows features only available on the 3420
machines to be configured.
1. Drill Fold - needs to be set to enabled for
3420 machines.
2. Rear Tow Hitch - set to enabled if unit is
equipped with the rear tow hitch option.
3. Treadlite System - set to enabled if unit is
equipped with the extra Treadlite tire option.
Figure 6.84 - Drill Fold Setup
4. Treadlite Drive - this option is controlled by
the same drive as the QDA so it will only
show up here if the drive hasn’t already been
set for the QDA. It will be Drive 2 on the
last CM-40 on the list.
5. Diagnostics - can enable diagnostics for
manually manipulating drill fold. Careful
attention is required in this mode to prevent
damage.
