X35 ConsoleProduct Setup
7.4
To see the calibration factor, first select a product
from the list on the left (selected product will
have white background). Next, select the "Show
Calibration Factors" button. A table with the
calibration factors will be displayed on the right
side of the screen, refer to Figure 7.4.
Figure 7.4 - Calibration Factors
The X35 console will save and display calibration
factors for each implement and tank that product
has been calibrated in, along with the flighting that
was entered for that tank.
There are two ways to add a new product to your
custom list:
1. Using a Bourgault product template list. This
is a preferred method.
or;
2. Adding a custom product without a template.
