Topcon X35 - Page 267

X35 Console
Trouble Shooting
12.3
12.3 Operation
SYMPTOM PROBABLE CAUSE SOLUTION
Monitor performs
slower than normal.
Using large VRC map Disable VRC map layer on the guidance screen. It
will still control the rate to the VRC map, just will
not display the prescription map on the screen. This
will improve monitor performance.
Monitor
automatically turns
off.
Low voltage.
Check battery voltage, alternator output, and power
cable wiring.
Blown fuse. Check for damaged wiring.
No ECU
communication
Profile not setup correctly.
Refer to Section 6.2 - Creating New Implement
Profile to setup profile and detect ECU(s).
Poor harness connection
Check all harness connections from ECU on air
seeder to monitor.
Incorrect harness
connection.
Ensure harnesses are connected properly. Refer to
Section 11 - Wiring Schematics.
Poor power supply Check battery voltage.
Poor fuse connections. Check fuse holder connections.
Blown fuse. Check for damaged wiring.
Faulty/damaged ECU. Contact Bourgault dealer.
Monitor and ECU software
versions are not compatible.
Check software versions. Refer to
Section 10.5
- System Information & Section 1.1.1 - Software
Version.
Intermittent sensor
readings.
Poor harness connection.
Check harness connections for dirt and/or corrosion.
Clean as required.
Incorrect sensor to target
adjustment.
Ensure proper to alignment and gap. Ensure that
the speed sensor to target gap is 1/32”-1/8” (1mm-
3mm). Refer to your Air Seeder Operator's manual.
Cannot reach target
metering rate.
Torque limiter on auger
shaft slipping.
Ensure metering auger shaft is turning freely (no
rubbing or foreign objects in housing).
Drive range in incorrect
range.
Change to higher range. For instructions refer to
your Air Seeder Operator's manual.
Rate too high. Lower rate.
Incorrect ground
speed display.
Incorrect wheel factor.
GPS speed prefered. If not available, complete a
distance check to verify wheel factor is incorrect.
If so complete a wheel factor calibration.
Incorrect sensor to target
adjustment.
Ensure proper alignment and gap. Ensure that the
ground speed sensor to target gap is 1/32”-1/8”
(1mm-3mm). Refer to your
Air Seeder Operator's
manual.
Incorrect area
accumulation.
Incorrect wheel factor.
GPS speed prefered. If not available, complete a
distance check to verify wheel factor is incorrect.
If so complete a wheel factor calibration.
Incorrect implement width. Enter correct implement width.
