X35 ConsoleOptional Equipment
13.14
Figure 13.17 - Blockage System Status - Seeder Controller Expanded View
Section/Blockage status
panel
b. With the Section/Blockage status panel in
Seeder Controller expanded view. Refer to
Figure 13.17.
i. Expand the Seeder Controller mini-
view window into main viewing area
by selecting maximize arrow.
ii. Select the Section/Blockage status
panel and slide up or down until
manifolds appear.
c. The colour of the manifold indicates status:
green - no blockage
red - there is a blocked run
d. Select (by touch) the manifold icon and it
will bring up the sensors list.
i. Sensors that report no blockage will
have a green background.
ii. Sensors that report a blockage will
have a red background.
4. If a blockage occurs, switch the master switch
OFF and stop the unit.
5. Obtain the list of plugged runs (refer to Step
3). Clear all blocked runs.
6. Resume seeding.
