X35 Monitor Air Seeder Setup
6.9
Select your drill configuration.
a. A naming convention is used to help easily identify required configuration.
b. Following examples explain the naming convention:
i. 3320-76 10SPCG - is a Model 3320, 76' width, 10" spacing
ii. 3320-76 12SPCG HF - is a Model 3320, 76 width, 12" spacing, High flotation frame
iii. 3320-66 10SPCG(GRAN SCN) HF - is a Model 3320, width 66', 10" spacing, granular
sectional control, High flotation frame
c. To enter a name select the "Implement
name" button and a keyboard will appear.
Type the desired name and select OK to
accept it.
Note
iv. 5810-62 9.8SPCG(GRAN SCN)
- is a Model 5810, width 62', 9.8"
spacing, granular sectional control
7. Enter the Implement Name
a. Refer to
Figure 6.7.
b. You can enter a specific name or accept
the automatically generated name.
Figure 6.7 - New Implement Name
