Test Functions
Issue 5 - 04/01 5-21
Choose CUSTOMER or OPERATOR. A screen similar to the
following is displayed:
CUSTOMER
Enter the cutomer or operator name you want to add.
Press ENTER to save the name and leave the screen.
Sending the Report
Connect AuroraPlus to the PC you want to send the results to
using the serial cable supplied with
AuroraPlus.
Set up your PC so that the serial port connected to
AuroraPlus
is set to the following:
bits per second 9600 bps
data bits 8
parity no parity
stop bits 1
flow control off
Open the terminal emulation programmed you are going to
use.
From the results menu choose TESTREPOR. The following
screen is displayed:
TESTREPORT
1 TEXT
2 CSV
Chap05.P65 01/05/01, 09:1221
