Using 2D Guidance in the Field 4
Creating a new depth model
1. From any guidance screen, press and hold Depth.
Note – You can also access Depth Memories by pressing Depth Memories from
the Guidance Method dialog.
2.
Press J until the highlight bar moves past the last item in the current list. A
new depth model is created, with a depth of zero.
3. Use any of the following tools to set the depth:
Edit the Depth field directly
Press +0.015 or –0.015 to add or subtract 0.015 m (0.6 inches) to or from
the current depth
Note – The actual softkey labels displayed depend on the
increment/decrement values that have been set and the units selected. For
more information on setting the increment/decrement values, see 3.9
Setting depth and slope increment values.
Press Set 0.00 to set the depth to zero
4.
To confirm the changes, press \; to exit without saving the changes, press
=.
GCS900 Grade Control System for Excavators Operator's Manual 83
