Chapter 2: Installation
2.1.4 Kit components: B094-008-2E-M-F Console Server
B094-008-2E-M-F8-portConsoleServerwithdualNICandmodem
2xCableUTPCat5blue
Connectors
DB9F-RJ45Sstraightandcross-over
External power supply
QuickStartGuideandCD-ROM
• UnpackyourConsoleServerkitandverifyyouhaveallthepartsshownabove,andtheyallappeartobeingoodworkingorder
• IfyouareinstallingyourConsoleServerinarack,youwillneedtoattachtherackmountingbracketssuppliedwiththe
unit and install the unit in the rack. Follow the Safety Precautions
• ProceedtoconnectyourConsoleServertothenetwork,totheserialportsofthecontrolleddevices,andtopoweras
outlined below
