5.5.2 Configuring client devices
Client devices on the local network must be configured with Gateway and DNS settings. This can be done statically on each
device,orusingDHCP
Manual Configuration:
Manuallysetastaticgatewayaddress(beingtheaddressoftheConsoleServer)andsettheDNSserveraddresstobethe
sameasusedontheexternalnetworki.e.iftheConsoleServerisactingasaninternetgatewayoracellularrouter,thenuse
theISPprovidedDNSserveraddress.
DHCP Configuration:
• NavigatetotheSystem:IPpage
• Clickthetaboftheinterfaceconnectedtotheinternalnetwork.TouseDHCP,astaticaddressmustbeset;checkthatthe
static IP and subnet mask fields are set.
• ClickontheDisabledlinknexttoDHCPServerwhichwillbringuptheSystem:DHCPServerpage
• CheckEnableDHCPServer
• ToconguretheDHCPserver,ticktheUseinterfaceaddressasgatewaycheckbox
• SettheDNSserveraddress(es),leasetimes,allocationpoolsandpre-assignedIPaddresses;asdetailedpreviouslyin
Chapter 3.6.2
Onceapplied,devicesontheinternalnetworkwillbeabletoaccessresourcesontheexternalnetwork.
