248

Connectors included in Console Server

TheB092-016ConsoleServerwithPowerAlert,andtheB096-048/016ConsoleServerManagementSwitchshipwitha

“cross-over”anda“straight”RJ45-DB9connectorforconnectingtoothervendor’sproducts:

Serial Port Connectivity

DB9F-RJ45Sstraightconnector 

DB9F-RJ45Scross-overconnector
