6.DISCHARGING CONTROL MODE
94
a) Complete signal output mode (Select from Judging Time / Judge & Stable / Judging / Stable)
b) Complete Output Time (Input range / 0.00 ~ 9.99)
c) Judging Time (Input range / 0.00 ~ 9.99)
d) Comparison Inhibit Time (Input range / 0.00 ~ 9.99)
e) Output Selection 2 (Select from Go output / Complete output)
Operation
a)
1) Select setting mode 2.
2) Select Compete signal output mode. (2-Weighing Function 2)
b)
1) Select setting mode1.
2) Input the Complete Output Time. (3-Complete Output Time)
→→→
F
CNG/ENT CNG/ENT
2
LOWER
Complete signal output mode
2 : ON for the Complete Output Time from when
the judging timer has expired or from when
the weight value becomes stable after the SP3
signal turns ON.
1 : ON for the Complete Output Time from when
the weight value becomes stable after
the judging timer has expired.
0 : ON for the Complete Output Time from when
the judging timer has expired.
→→
→
ZERO
2
LOWER
CNG/ENT CNG/ENT
ZERO ZEROZERO
→→→
F
CNG/ENT CNG/ENT
1
UPPER
→→ →
Complete Output Time (sec.)
(0.00 ~ 9.99)
CNG/ENT CNG/ENT
3
NEAR Z .
