6.DISCHARGING CONTROL MODE
84
Example) Final 20.000
AFFC. 0.100
Average count of AFFC. 4
AFFC. coefficient 2/4
* When Compensation value is changed, average count of AFFC. becomes 0.
Times Actual
Weighing
Error Average count of
AFFC.
CPS
When negative CPS
is inhibit.
When negative CPS
is effect.
00
← Power ON
1 20.050 +0.050 1 0.500 -0.033
2 20.040 +0.040 2 0.500 -0.033
3 20.070 +0.070 3 0.500 -0.033
4 20.080 +0.080
4 → 0
0.500 -0.033
+0.240/4 = 0.060
0.060×2/4 = 0.030
→ CPS Value
5 20.020 +0.020 1 0.530 -0.003
6 20.000 0.000 2 0.530 -0.003
7 20.010 +0.010 3 0.530 -0.003
8 20.110 (+0.110)
← ×3
0.530 -0.003
9 20.010 +0.010
4 → 0
0.530 -0.003
+0.040/4 = 0.010
0.010×2/4 = 0.005
→ CPS Value
10 19.880 (-0.120)
← ×1
0.535 0.002
11 19.990 -0.010 1 0.535 0.002
12 20.010 +0.010 2 0.535 0.002
13 20.000 0.000 3 0.535 0.002
14 19.980 -0.020
4 → 0
0.535 0.002
-0.020/4 = -0.005
-0.005×2/4 = -0.003
→ CPS Value
0.532 -0.001
Setting compensation coefficient
Compensation coefficient can be selected from 1/4, 2/4, 3/4, or 1.
You can get more accurate compensation value by selecting 1 when each
weight value is approximate same in each measuring or by selecting 1/4 ~ 2/4
when each weight value fluctuates in each measuring.
To Next Page
