6.DISCHARGING CONTROL MODE
85
Setting compensation parameter
a) AFFC. Set the regulated value to avoid the compensation value
becomes extremely large (or small).
(Input range / 0 ~ 99999)
b) AFFC. ON/OFF Selection of AFFC.
When CC-Link is installed, writing of free fall compensation
data can be prohibited, at the time of writing in the exclusive
data area.
(Select from OFF, ON, ON
(Communication OP invalid))
c) Average count of AFFC. Number of weighing value for calculating the average of
compensation.
(Input range / 1 ~ 9)
d) AFFC. coefficient Setting for avoiding fluctuations of the compensation value be
computed by multiplying the compensation and the coefficient
of not more than 1.
(Select from 1, 3/4, 2/4 or 1/4)
a)
1) Select setting mode 1.
2) Input the AFFC.. (7-Auto Free Fall Compensation Regulation)
b), c), d)
1) Select setting mode 2.
2) Set AFFC. ON/OFF, average count of AFFC. and AFFC. coefficient.
(3-Weighing Function 3)
→→→
F
CNG/ENT CNG/ENT
1
UPPER
→→ →
Auto Free Fall Compensation Regulation
(0 ~ 99999)
7
OVER
CNG/ENT CNG/ENT
→→→
F
CNG/ENT CNG/ENT
2
LOWER
3 : AFFC. coefficient 1/4
2 : 〃 2/4
1 : 〃 3/4
0 : 〃 1
Average count of AFFC.
(1 ~ 9)
→→ →
CNG/ENT CNG/ENT
3
NEAR Z
.
2 : AFFC. ON
(Communication OP invalid)
1 : 〃 ON
0 : 〃 OFF
ZERO
To Next Page
