6.DISCHARGING CONTROL MODE
87
a) Final (Input range / 0 ~ 99999)
b) Set Point 2 (Input range / 0 ~ 99999)
c) Set Point 1 (Input range / 0 ~ 99999)
d) Compensation (Input range / 0 ~ 9999: When negative compensation is inhibit)
(Input range / -9999 ~ 9999: When negative compensation is effect)
e) Over (Input range / 0 ~ 999)
f) Under (Input range / 0 ~ 999)
* Not for using Set Point 1 and Set Point 2, make the settings of Set Point 1 and Set Point 2 equal
to the Final.
Operation
a)
1) Select setting mode 0.
2) Input the Final. (9-Final)
b)
1) Select setting mode 0.
2) Input the Set Point 2. (5-Set Point 2)
→→→
F
CNG/ENT CNG/ENT
0
→→ →
Final
(0 ~ 99999)
9
FINAL
CNG/ENT CNG/ENT
→→→
F
CNG/ENT CNG/ENT
0
→→ →
Set Point 2
(0 ~ 99999)
CNG/ENT CNG/ENT
5
SP2
