Table 24: Monitoring of the advanced values
Index Monitoring value Unit Scale ID Description
V2.6.4
Application Status
Word2
1 90
Bit-coded statuses of the application. The
values are visible as checkboxes on graphical
display. If a box is ticked, the value is active.
B0 = Acc/Dec prohibited
B1 = Motor switch open
B5 = Jockey pump active
B6 = Priming pump active
B7 = Input pressure supervision (Alarm/
Fault)
B8 = Frost protection (Alarm/Fault)
B9 = Autocleaning active
V2.6.5 DIN Status Word 1 1 56
A 16-bit word where each bit shows the
status of 1 digital input. 6 digital inputs from
each slot are read. Word 1 starts from the
input 1 in slot A (bit0) and goes all the way to
input 4 in slot C (bit15).
V2.6.6 DIN Status Word 2 1 57
A 16-bit word where each bit shows the
status of 1 digital input. 6 digital inputs from
each slot are read. Word 2 starts from the
input 5 in slot C (bit0) and goes all the way to
input 6 in slot E (bit13).
V2.6.7
Motor current 1
decimal
0.1 45
The monitor value of the motor current with
fixed number of decimals and less filtering.
This can be used for example with fieldbus to
get the correct value so that the frame size
does not have an effect. or for monitoring
when less filtering time is needed for the
motor current.
V2.6.8
Frequency
reference source
1 1495
Shows the momentary frequency reference
source.
0 = PC
1 = Preset Freqs
2 = Keypad Reference
3 = Fieldbus
4 = AI1
5 = AI2
6 = AI1+AI2
7 = PID Controller
8 = Motor Potentiom.
9 = Joystick
10 = Jogging
100 = Not defined
101 = Alarm,PresetFreq
102 = Auto-cleaning
V2.6.9
Last active fault
code
1 37
The fault code of the last fault that has not
been reset.
VACON · 106 MONITORING MENU
4
TEL. +358 (0)201 2121 · FAX +358 (0)201 212 205
