Vacon 100 Applications Manual

Table 120: The output signals through RO1
Selection
number
Selection name Description
43
Mechanical brake control
(Inverted)
The Open mechanical brake command (inverted).
44
Block Out.1 The output of the programmable Block 1. See parameter
menu M3.19 Drive customizer.
45
Block Out.2 The output of the programmable Block 2. See parameter
menu M3.19 Drive customizer.
46
Block Out.3 The output of the programmable Block 3. See parameter
menu M3.19 Drive customizer.
47
Block Out.4 The output of the programmable Block 4. See parameter
menu M3.19 Drive customizer.
48
Block Out.5 The output of the programmable Block 5. See parameter
menu M3.19 Drive customizer.
49
Block Out.6 The output of the programmable Block 6. See parameter
menu M3.19 Drive customizer.
50
Block Out.7 The output of the programmable Block 7. See parameter
menu M3.19 Drive customizer.
51
Block Out.8 The output of the programmable Block 8. See parameter
menu M3.19 Drive customizer.
52
Block Out.9 The output of the programmable Block 9. See parameter
menu M3.19 Drive customizer.
53
Block Out.10 The output of the programmable Block 10. See parameter
menu M3.19 Drive customizer.
54 Jockey pump control The control signal for the external jockey pump.
55 Priming pump control The control signal for the external priming pump.
56 Auto-cleaning active The Pump auto-cleaning function is activated.
57
Motor Switch Open The Motor Switch function has detected that the switch
between the drive and the motor is open.
58 TEST (Always Closed)
59 Motor preheat active
9.7.6 ANALOGUE OUTPUTS
P3.5.4.1.1. AO1 FUNCTION (ID 10050)
The contents of the analogue output signal 1 are specified in this parameter. The scaling of
the analogue output signal depends on the signal.
PARAMETER DESCRIPTIONS VACON · 271
24-HOUR SUPPORT +358 (0)201 212 575 · EMAIL: VACON@VACON.COM
9

Vacon 100 Specifications

General

Product type	AC Drive
Enclosure class	IP20
EMC filter	Built-in
Power	0.25 kW - 5.5 kW
Cooling method	Fan
Braking chopper	Optional
