6 DIAGNOSTICS MENU
6.1 ACTIVE FAULTS
When there is a fault or many faults, the display shows the name of the fault and blinks. Push
OK to go back to the Diagnostics menu. The submenu Active faults shows the number of
faults. To see the fault-time data, make a selection of a fault and push OK.
The fault stays active until you reset it. There are 4 ways to reset a fault.
•
Push the Reset button for 2 s.
•
Go into the submenu Reset faults and use the parameter Reset Faults.
•
Give a reset signal in the I/O terminal.
•
Give a reset signal with the fieldbus.
The Active faults submenu can keep a storage of maximum 10 faults. The submenu shows
the faults in the sequence in which they occurred.
6.2 RESET FAULTS
In this menu, you can reset faults. See instructions in Chapter 10.1 A fault comes into view.
CAUTION!
Before you reset the fault, remove the external Control signal to prevent that you
restart the drive.
6.3 FAULT HISTORY
You can see 40 faults in the Fault history.
To see the details of a fault, go into Fault history, find the fault and push OK.
6.4 TOTAL COUNTERS
If you read a counter value through fieldbus, see Chapter 9.19 Total and trip counters.
VACON · 204 DIAGNOSTICS MENU
