Vacon 100 Applications Manual

4.1.6 EXTRAS AND ADVANCED
Table 24: Monitoring of the advanced values
Index Monitoring value Unit Scale ID Description
V2.6.1 Drive Status Word 1 43
The bit-coded word
B1 = Ready
B2 = Run
B3 = Fault
B6 = RunEnable
B7 = AlarmActive
B10 = DC current in stop
B11 = DC brake active
B12 = RunRequest
B13 = MotorRegulatorActive
V2.6.2 Ready status 1 78
Bit-coded data about ready criteria. This data
is useful for monitoring when the drive is not
in the Ready state. The values are visible as
checkboxes on the graphical display. If a box
is ticked, the value is active.
B0 = RunEnable high
B1 = No fault active
B2 = Charge switch closed
B3 = DC voltage within limits
B4 = Power manager initialised
B5 = Power unit is not blocking start
B6 = System software is not blocking start
V2.6.3
Application Status
Word1
1 89
Bit-coded statuses of the application. The
values are visible as checkboxes on graphical
display. If a box is ticked, the value is active.
B0 = Interlock 1
B1 = Interlock 2
B2 = Reserved
B3 = Ramp 2 active
B4 = Mechanical brake control
B5 = I/O A control active
B6 = I/O B control active
B7 = Fieldbus Control Active
B8 = Local control active
B9 = PC control active
B10 = Preset frequencies active
B11 = Jogging active
B12 = Fire Mode active
B13 = Motor Preheat active
B14 = Quick stop active
B15 = Drive stopped from keypad
MONITORING MENU VACON · 105
24-HOUR SUPPORT +358 (0)201 212 575 · EMAIL: VACON@VACON.COM
