Table 24: Monitoring of the advanced values
Index Monitoring value Unit Scale ID Description
V2.6.10 Last active fault ID 1 95
The fault ID of the last fault that has not been
reset.
V2.6.11
Last active alarm
code
1 74
The alarm code of the last alarm that has not
been reset.
V2.6.12
Last active alarm
ID
1 94
The alarm ID of the last alarm that has not
been reset.
4.1.7 TIMER FUNCTIONS MONITORING
Monitor the values of Timer functions and the Real Time Clock.
Table 25: Monitoring of the timer functions
Index Monitoring value Unit Scale ID Description
V2.7.1 TC 1, TC 2, TC 3 1 1441
You can monitor the statuses of the 3 time
channels (TC)
V2.7.2 Interval 1 1 1442 The status of the timer interval
V2.7.3 Interval 2 1 1443 The status of the timer interval
V2.7.4 Interval 3 1 1444 The status of the timer interval
V2.7.5 Interval 4 1 1445 The status of the timer interval
V2.7.6 Interval 5 1 1446 The status of the timer interval
V2.7.7 Timer 1 s 1 1447
The remaining time on the timer if the timer
is active
V2.7.8 Timer 2 s 1 1448
The remaining time on the timer if the timer
is active
V2.7.9 Timer 3 s 1 1449
The remaining time on the timer if the timer
is active
V2.7.10 Real time clock 1450 hh:mm:ss
