6
Set a value for P3.1.1.5 Motor Cos Phi (so that it
agrees with the nameplate of the motor)
Range: 0.30…1.00
7
Set a value for P3.3.1.1 Minimum Frequency
Reference
Range: 0.00…P3.3.1.2 Hz
8
Set a value for P3.3.1.2 Maximum Frequency
Reference
Range: P3.3.1.1…320.00 Hz
9 Set a value for P3.4.1.2 Acceleration Time 1 Range: 0.1…300.0 s
10 Set a value for P3.4.1.3 Deceleration Time 1 Range: 0.1…300.0 s
The Multi-step speed application wizard is completed.
2.4 PID CONTROL APPLICATION WIZARD
The application wizard helps you to set the basic parameters that are related to the
application.
To start the PID control application wizard, set the value PID control to parameter P1.2
Application (ID 212) in the keypad.
NOTE!
If you start the application wizard from the startup wizard, the wizard goes directly
to the question 11.
1
Set a value for P3.1.2.2 Motor Type (so that it agrees
with the nameplate of the motor)
PM motor
Induction motor
2
Set a value for P3.1.1.1 Motor Nominal Voltage (so
that it agrees with the nameplate of the motor)
Range: Varies
3
Set a value for P3.1.1.2 Motor Nominal Frequency
(so that it agrees with the nameplate of the motor)
Range: 8.00…320.00 Hz
4
Set a value for P3.1.1.3 Motor Nominal Speed (so
that it agrees with the nameplate of the motor)
Range: 24…19200 rpm
5
Set a value for P3.1.1.4 Motor Nominal Current (so
that it agrees with the nameplate of the motor)
Range: Varies
If you set Motor Type to Induction Motor, you see the next question. If your selection is PM
Motor, the value of parameter P3.1.1.5 Motor Cos Phi is set to 1.00, and the wizard goes
directly to question 7.
VACON · 66 WIZARDS
2
TEL. +358 (0)201 2121 · FAX +358 (0)201 212 205
