Vacon 100 Applications Manual

4.1.12 FIELDBUS DATA MONITORING
Table 30: Fieldbus data monitoring
Index Monitoring value Unit Scale ID Description
V2.12.1 FB Control Word 1 874
The fieldbus control word that the application
uses in bypass mode/format. Depending on
the fieldbus type or profile, the data can be
modified before it is sent to the application.
V2.12.2
FB Speed
Reference
Varies 875
The speed reference scaled between the
minimum and the maximum frequency at the
moment when the application received it. You
can change the minimum and the maximum
frequencies after the application received the
reference without an effect on the reference.
V2.12.3 FB data in 1 1 876
The raw value of process data in a 32-bit
signed format
V2.12.4 FB data in 2 1 877
The raw value of process data in a 32-bit
signed format
V2.12.5 FB data in 3 1 878
The raw value of process data in a 32-bit
signed format
V2.12.6 FB data in 4 1 879
The raw value of process data in a 32-bit
signed format
V2.12.7 FB data in 5 1 880
The raw value of process data in a 32-bit
signed format
V2.12.8 FB data in 6 1 881
The raw value of process data in a 32-bit
signed format
V2.12.9 FB data in 7 1 882
The raw value of process data in a 32-bit
signed format
V2.12.10 FB data in 8 1 883
The raw value of process data in a 32-bit
signed format
V2.12.11 FB Status Word 1 864
The fieldbus status word that the application
sends in bypass mode/format. Depending on
the fieldbus type or profile, the data can be
modified before it is sent to the fieldbus.
V2.12.12 FB Speed Actual 0.01 865
The actual speed as a percentage. The value
0% agrees with the minimum frequency and
the value 100% agrees with the maximum
frequency. This is continuously updated
depending on the momentary min and max
frequencies and the output frequency.
V2.12.13 FB data out 1 1 866
The raw value of process data in a 32-bit
signed format
V2.12.14 FB data out 2 1 867
The raw value of process data in a 32-bit
signed format
MONITORING MENU VACON · 111
