Vacon 100 Applications Manual

5.6 GROUP 3.6: FIELDBUS DATA MAPPING
Table 59: Fieldbus data mapping
Index Parameter Min Max Unit Default ID Description
P3.6.1
Fieldbus Data Out 1
Selection
0 35000 1 852
Make the selection of
the data that is sent to
fieldbus with the ID of
the parameter or
monitor. The data is
scaled to an unsigned
16-bit format
according to the format
on the control panel.
For example, 25.5 on
the display agrees with
255.
P3.6.2
Fieldbus Data Out 2
Selection
0 35000 2 853
Make the selection of
the Process Data Out
with the parameter ID.
P3.6.3
Fieldbus Data Out 3
Selection
0 35000 3 854
Make the selection of
the Process Data Out
with the parameter ID.
P3.6.4
Fieldbus Data Out 4
Selection
0 35000 4 855
Make the selection of
the Process Data Out
with the parameter ID.
P3.6.5
Fieldbus Data Out 5
Selection
0 35000 5 856
Make the selection of
the Process Data Out
with the parameter ID.
P3.6.6
Fieldbus Data Out 6
Selection
0 35000 6 857
Make the selection of
the Process Data Out
with the parameter ID.
P3.6.7
Fieldbus Data Out 7
Selection
0 35000 7 858
Make the selection of
the Process Data Out
with the parameter ID.
P3.6.8
Fieldbus Data Out 8
Selection
0 35000 37 859
Make the selection of
the Process Data Out
with the parameter ID.
PARAMETERS MENU VACON · 151
